7W IP65 round open-frame LED bollard lights along a villa garden path
Square 7W IP65 LED bollard light with an open-frame design and 360° illumination. Three heights suit paths, planting areas and commercial landscapes.
Square Bollard Light with a Clean Open Frame
This 7W bollard uses a square open-frame structure to provide 360° guidance lighting. Three height options allow the same design to be used across paths, planting beds and entrances.
Key Features
- Three Heights: Available in 200, 400 or 600 mm.
- Square Open Frame: Matches modern buildings and landscape layouts.
- 360° Illumination: Provides light around the fixture and walking area.
- IP65 Protection: Designed for correctly installed outdoor projects.
- Compact 110 mm Footprint: Fits narrow paths and planting areas.
Models and Dimensions
| Model | Power | Dimensions |
|---|---|---|
| DB-CPDA093-20H7W | 7W | 110 × 110 × H200 mm |
| DB-CPDA093-40H7W | 7W | 110 × 110 × H400 mm |
| DB-CPDA093-60H7W | 7W | 110 × 110 × H600 mm |
Common Specifications
| Light Source | 7W COB |
| Input Voltage | AC 85–265V, 50/60Hz |
| Beam Angle | 360° |
| Luminous Efficacy | 70–80 lm/W |
| CRI | Ra >80 |
| Colour Temperature | 3000K / 6000K |
| Housing Colour | Black |
| Material | Aluminium alloy |
| IP Rating | IP65 |
| Certification | CE / RoHS |
| Warranty | 3 years |
Choosing the Height
200 mm: Steps, low planting and pathway edges.
400 mm: Courtyards, residential paths and garden areas.
600 mm: Hotel walkways, entrances and larger landscape projects.
Applications
Suitable for hotel courtyards, villa gardens, residential paths, commercial entrances, parks and public walkways.
OEM and ODM Support
DAYBREAK supports wholesalers, contractors and project buyers with OEM labels, customised packaging and project-based production.
Request a Quote
Send us the required height, quantity, colour temperature and installation plan. We can provide a datasheet, sample or quotation.
